Stacking (Series)
HUB 10.3
Stacking (Parallel)
HUB 10.3
900-0154-01-00 REV B.vsd\2014-03-03
©2013 OutBack Power Technologies. All Rights Reserved.
900-0154-01-00 REV B.vsd\2014-03-03
©2013 OutBack Power Technologies. All Rights Reserved.
Series Stack (OutBack)
Up to 10 inverters or other devices; requires balancing transformer
Master inverter and half of the Slave inverters use common output AC bus (L1)
The remaining Slave inverters use a separate common AC bus (L2)
Master inverter is always active; regulates output based on load;
can power both L1 and L2 buses using balancing transformer
Slave inverters remain in Power Save mode; Master activates
any Slave inverters for either L1 or L2 based on load
Series Stack (Classic)
2 inverters; up to 8 other devices
Master and single Slave inverter use separate output AC buses
(L1 and L2)
Both inverters always active
(no Power Save mode);
outputs are loaded independently
but output regulation is controlled
by load on Master
1 st
MATE
X
10 9 8 7 6 5 4 3 2
1
Port 1
Stack Mode Master or 1-2phase Master
Parallel Stack
Up to 10 inverters or other devices
All inverters use common AC output bus
Master inverter always active; regulates power output based on load
Slave inverters remain in Power Save mode; Master activates
Slave inverters based on load
Slave (port 2, port 3, etc.)
Jumper position
(see step 4b
on front page)
or
(with
FX-class
inverter)
FX / VFX (includes
J, M, N Series)
GTFX
GVFX
GTFX (LA Series)
GVFX (LA Series)
Models
GFX
Ports 2 to 10 can be assigned to either
OB Slave L1 or OB Slave L2;
equal numbers of inverters should be
assigned to each side
Port 1
Stack Mode Master or 1-2phase Master
Port 2
Stack Mode OB Slave L1
or
OB Slave L2
FX / VFX (includes
J, M, N Series)
Models
Master (port 1 only)
Port 2
Stack Mode Slave or OB Slave L1
Port 1
Stack Mode Master or 1-2phase Master
Master (port 1 only)
Slave (port 2)
Jumper position
(see step 4b
on front page)
10 9 8 7 6 5 4 3 2
1
X
1 st
MATE
Master (L1)
Jumper
position
(see step 4b
on front page)
Master Slave Slave Slave Slave Slave Slave Slave
Slave (L2)
Port 2
Stack Mode Classic Slave
or
or
Master (port 1 only)
Slave (port 2)
Models
FX / VFX (all series,
including E, J, M, N,
and W)
GS8048A
GFX
GFX (E Series)
GTFX (E Series)
GVFX (ESeries)
GS4048A
GS7048E
GS3548E
GS8048
Split-phase
inverters:
Single-phase
inverters:
Output
Single-phase output
Split-phase output
Single-phase
inverters:
Split-phase output
Output
Single-phase
inverters:
Split-phase output
Output
10 9 8 7 6 5 4 3 2
1
X
1
st
MATE
Slave (L2) Slave (L2) Slave (L2) Slave (L2) Slave (L2) Slave (L1) Slave (L1) Slave (L1) Slave (L1) Master (L1)
