Welcome to OutBack Power Systems’ FLEXware
FLEXware is a convenient all-aluminum power system offering simpler, code-compliant instal-
lation of OutBack power electronics components. Three versions of FLEXware are available:
• FLEXware 250 for single FX Series Inverter/Charger installations along with the desired AC
and DC disconnects
• FLEXware 500, which supports up to two FXs and two MX Charge Controllers, accommodat-
ing both split-phase and/or higher power output as needed
• FLEXware 1000 accommodates up to four FXs and four MX Charge Controllers
Please Note: Both the FLEXware 500 and the FLEXware 1000 power systems provide locations
for FW-X240 Auto-Transformers, multiple DC shunts and other essential components required
in higher kW systems.
FLEXware Mounting Plate Parts List
The following parts are included with every FLEXware Mounting Plate:
• one 46.26” X 20.25” aluminum mounting plate
• fourteen M6 X 10 mm screws
four “hanging” screws to assist with FX Series Inverter/Charger installations
eight for securing the AC enclosure and the DC enclosure
two extras
• ten M6 X 20 mm screws for securing two FX Series Inverter/Chargers to the FW-MP plus two
extras
• twenty-six M6 star washers, used with the M6 screws for grounding
• eight 1/4 X 5/8 flat washers, used with M6 screws attaching the enclosures to the FW-MP
• #3 Phillips bit
