7

Notes:

• The FW-X240 should be installed inside the FW1000

after the FW1000 is secured to the FLEXware
Mounting Plate.

• The FW-X240 can be fastened to other surfaces

providing the surface and fasteners used can safely
sustain a weight in excess of 25 lbs.

Figure 3 FW1000 AC Chassis

MOUNTING SL

O

TS

(HARD

W

ARE

INCL

UDED)
