Installing The Base Platform
After the wall plate has been safely secured to the wall. Insert the base platform into the wall plate as shown
in fig.2.1.
fig. 3.1
2
Installing XBOX360 KINECT Sensor
• Take the sensor base and line it up with the base of the
• Press in both grips on the sensor base and fit the sensor base onto the bottom of the
. Release the grips of the sensor base to lock the two together as shown in fig. . .
XBOX360 KINECT Sensor.
XBOX360 KINECT
Sensor 3 1
3
Insert the sensor base with attached into the base platform until you hear a
“click”
XBOX360 KINECT Sensor
as shown in fig.3.2.
Note: the sensor base
switch is pointed at the
back.
XBOX360 KINECT Sensor
. is not included
Removing The Sensor Base With Attached XBOX360 KINECT Sensor.
as shown in
fig.4.1.
To remove the sensor base with attached pull the sensor base switch forward
and remove the sensor base with attached from the base platform
XBOX360 KINECT Sensor,
XBOX360 KINECT Sensor
4
fig. 4.1
