NOTE: Please read Instruction Manual prior to installation.
WARNING
• Do not begin installation until you have read and understood the instructions and
warnings contained in this manual. If you need further assistance, please contact
your local distributor.
• Please refer to manufacture’s installation guide for recommended distance from
wall to avoid risk of property damage.
• This product should only be installed by someone of good mechanical aptitude and
basic building experience to avoid malfunction.
• Make sure that the supporting surface will safely support the combined load of the
equipment and all attached hardware and components.
• Always use an assistant or mechanical lifting equipment to safely lift and position
equipment.
• Tighten screws firmly, but do not over tighten. Over tightening can damage the items,
greatly reducing their holding power.
• This product is for indoor use only. (Use of this product outdoors could lead to product
failure and personal injury).
2 1
Component Checklist
Please ensure you have received all parts listed on the component checklist prior to installing. If any parts are
missing or faulty, contact your local distributor for replacement.
Package W
Tools required
Phillips Head Screw driver(200mm length exclude the handle)
Electric drill and 6mm masonry bit for concrete wall installation
Marking Pen
Hammer ·
·
·
·
ST3.5x32 (x4)
W-A
concrete anchor
W-B
(x4)
sensor base
C
(x1) base platform
B
(x1) wall plate
A
(x1)
