Monoprice 8101 MVD-19 User Manual
Installation instructions dvd wall mount, Model: mvd-19
INSTALL TV
3
INSTALLATION INSTRUCTIONS
DVD Wall Mount
Max Load Capacity: 10kg(22lbs)
10kg
(22lbs)
MAX
Model: MVD-19
Assembled the glass panel mounted clamps and bracket
align the mounting holes on the bracket with the holes on the clamp, using appropriate combination of screws
and then tighten screws with allen key. Do not over tighten! as shown in fig.2.2 and fig.2.3
Attach the adapter bracket between TV bracket and the back of the TV ,align to mounting holes, ,using the
appropriate combination of screws. as shown in fig.3.1 and fig.3.2.
3
fig.2.2
fig.2.3
M-B
M-D
M-B
M-D
fig.3.1
fig.3.2
