Levelling mount – Monoprice 8587 PLB-110B-R User Manual
Page 5
5
Thanks for choosing our products, enjoy the using.
Levelling Mount
Step 4
Diagram 4
WARNING
Use two people to lift and position the TV onto the Wall Plate
.
You can re-level the mount after the mount has been installed on the wall. Leveling is achieved by rotating the front plate
the TV sits on. Needn
’t to loose the 5 bolts on the front plate, just hold the TV and do the adjustment. See Diagram 4 below.
