INSTALLATION INSTRUCTIONS
LED WALL MOUNT
Model: MED-028
Max Load Capacity: 50kg(110lbs)
50kg
(110lbs)
MAX
7
4 Locking Adapter Brackets
fig. 4.1
fig. 4.2
The safety straps can be folded and
keep in back of the display.
• First, pull the outside safety straps on the adapter brackets, and then slowly
allow display to return to the wall. Finally loosen the safety straps and lock the
adapter brackets.
Important: Make sure the TV is correctly hooked and the safety locking bars are locked safely.
Maintenance
• Once you have mounted the bracket and the flat screen, check that they are
sufficiently secure and safe to use,
• You should regularly check that the screws and hardware are secure to your wall every
two months for safety.
• If you have any doubts regarding the installation, please consult our retailer or service
department for further details.
