SPECIFICATIONS:
General
Supported Protocols TCP/IP, PPPoE, DHCP (client & server), PPTP client for DSL connection,
NTP (Network Time Protocol), RIPI
Firewall /Alert NAT, Stateful Packet Inspection (SPI), DoS (Denial of Service), Attack
Alert (Email) /Logging, Access Control
VPN Pass Through PPTP, IPSec, L2TP
Network Interface 5 Ethernet:
4 * 10/100BaseT (RJ45) LAN connection
1 * 10/100BaseT (RJ45) for WAN
Management Web-based management, Remote Management
Functions Auto detects and configures ISP type, Exposed Host (DMZ), MAC Address
authentication, URL Content Filtering
Applications Dynamic DNS, UpnP, Virtual Server, Special Internet Applications, Multi-
DMZ, Dial-on-Demand and Auto-Disconnect, Authentication with PAP
and CHAP for PPPoE
Firmware Upgrade HTTP, TFTP download or proprietary network protocol download
LED Indicators 12 LEDs (Power, Status, WAN, 4 x LAN Link/Act, 4 x LAN, WLAN)
Power Adapter 12 V, 800mA (DC External)
Throughput WAN – LAN: 50 Mbps,
WAN – WLAN: 17~20 Mbps,
WLAN – LAN: 17 ~ 20 Mbps
Wireless Interface
Standards IEEE802.11g WLAN, JEIDA 4.2, roaming support
Frequency 2.4 to 2.4835GHz (Industrial Scientific Medical Band )
Channels Maximum 14 Channels, depending on regulatory authorities
Modulation DSSS BPSK/QPSK/CCK, OFDM/CCK
Data Rate Up to 54 Mbps
Coverage Area Indoors : 15m @54Mbps, 120m @6Mbps or lower
Outdoors : 40m @54Mbps, 300m @6Mbps or lower
WEP 64Bit, 128Bit
Transmit Power 13.5~16.5 dBm
Receiver Sensitivity -80dBm Min.
Wireless Antenna 2 type, solder on board or a detachable antenna, using IWF242 type antenna
Environmental
Operating
Temperature 0 ° C to 40° C
Storage Temperature -10 ° C to 70° C
Regulatory
EMI/RFI CE
Physical
Dimensions 141mm(W) * 100mm(D) * 27mm(H)
