Installation Instructions
Model Name:MHF-26 Universal Wall Mount
Flat panel 10"-26"
Important Note
Component Checklist
Front plate(x1)
panel(x1)
Past List
Mounting the wall plate
This bracket supports plasma,LCD displays,the maximum loading capacity
is 30lbs.
VESA: 75x75 3"x3" 100x100 4"x4" compatible.
Hexagonal screw
Concrete anchor(x4)
Concrete anchor
Cross pan head screw
Iron spacer
Iron spacer
Hexagonal screw
NOTE: Use a level to ensure
the wall plate is horizontal
Fix the front plate on the display screen
NOTE:Make sure the installation in accordance
with following pictures.
VESA 75x75 / 100x100
Cross pan head screw
