For Flat Back Screen
C.1
C.2
SCREEN
SCREW SPACER
SCREEN
fig C.1.1 fig C.1.2
SCREW
Front Plate Front Plate
OR
‡ Do not tighten screws with excessive force.
Overtightening can cause damage to mount.
CAUTION
‡ Do
After the locked front plate is hanging on the wall panel ,
use a M4x12 philips pan head to fix these two
parts.
Be careful when you operate this bracket,or you may
damage your screen.
not lift more weight than you can handle. Use
additional man power or mechanical lifting equipment
to safely handle placement of the screen.
WARNING
Select the small,medium,large or extra large screws from the screw package .Fastener pack then
attach screen brackets(AA) to screen following figure C.1.1 or C.1.2 on page 7.
fig.C.2.1
