Alcatel-Lucent 7705 SAR | Data Sheet 4
Technical specifications
Modules and adapter cards
• Control and switch module (CSM)
• 8-port Ethernet adapter card
(six ports of 10/100 Ethernet, two
ports of 10/100/1000 Ethernet)
• 16-port T1/E1 Any Service, Any
Port (ASAP) adapter card
Services
• TDM pseudowires
¬ RFC 5086 Structure-Aware
Time Division Multiplexed
(TDM) Circuit Emulation Service
over Packet Switched Network
(CESoPSN)
• ATM pseudowires
¬ RFC 4717 Encapsulation
Methods for Transport of
Asynchronous Transfer Mode
(ATM) over MPLS Networks
¬ N:1 cell mode, virtual circuit
connection and virtual path
connection
¬ ATM IMA
• Ethernet pseudowires
¬ RFC 4448 Encapsulation
Methods for Transport of
Ethernet over MPLS Networks
¬ Raw and tagged mode
Synchronization
• External reference timing
• Line timing
• Adaptive timing
• Built-in Stratum-3 clock
• Hardware-ready to support
IEEE 1588v2
Redundancy and resiliency
• Control
• Fabric
• Synchronization
• Uplinks
• MPLS tunnel
• Power feeds
Traffic management and QoS
• Hierarchical queuing
• Multi-tier scheduling
• Profiled (in and out of profile)
scheduling
• Queue type-based scheduling
• Ingress policing and egress shaping
• Up to 8 queues per service
• Memory allocation per queue
(CBS, MBS per queue)
• Premium, assured and best-effort
forwarding classes
• WRED on ingress and egress
• Classification based on:
¬ Layer 1/Layer 2/Layer 2.5
and/or Layer 3 header
¬ Timeslot/port
¬ Ethernet port/VLAN
¬ ATM service category:
(CBR/rt-VBRrt-VBR/UBR)
¬ ATM VC
¬ Ethernet 802.1p/VLAN
¬ IP DSCP/MPLS EXP
• Marking based on:
¬ Layer 2 (802.1p)
¬ Layer 2.5 (EXP) both for
tunnel and PWE3
¬ Layer 3 (DiffServ)
Security (node access)
• User ID/password-based
authentication and authorization
¬ Exponential login backoff
for brute force attacks
¬ Local or remote storing
of user-info
• Remote authentication/
authorization via Remote
Authentication Dial In User
Service (RADIUS) and Terminal
Access Controller Access-Control
System (TACACS)
• Secure Shellv2, Secure File
Transfer Protocol and Simple
Network Management Protocol
(SNMP) Version 3
¬ Secure open interfaces
• Syslog
¬ Capture security logs on
local or remote server
• Alarm on suspicious sequence
of operations
• Nodal attack
• Basic firewall with filtering
of control plane traffic
• Denial of service (DoS) attack
prevention (rate-limiting and
prioritization)
• Data security
• Transfer over peer-to-peer tunnel
(MPLS)
• MD5 authentication
• Sequence numbers prevent
replaying of data
• Statistics available on suspicious
behavior
Management
• Fully-featured, industry-standard
command line interface
• Port and service mirroring
• Service assurance tools, including
LSP ping, LSP traceroute, SDP
ping, VCCV
• SSH and Telnet
• FTP, Trivial File Transfer Protocol
and Secure Copy Protocol
• RADIUS (AAA)
• TACACS+
• SNMP v2/v3
Safety standards and
regulatory compliance
• Safety: CSA 60950-1 2001
• EMC:
¬ EN55022 1998 (Class A)
¬ FCC Part 15 - 2003 (Class A)
Physical dimensions
• Height: 2 RU, 8.9 cm (3.5 in.)
• Depth: 25.4 cm (10 in.)
• Width: 48.3 cm (19 in.)
• Rack mountable in a 30 cm x
45 cm (11.8 in x 17.7 in.) rack
Power
• -48v feeds, 180 W maximum
draw
Cooling
• One tray of eight fans
Operating environment
• Normal operating temperature
range: -5°C to +45°C
(23°F to 113°F)
• Short term (96 hours) extended
temperature range: -5°C to +55°C
(23°F to 131°F)
• Normal humidity: 5% to 85%
• Short term (96 hours) extended
humidity range: 5% to 95%
Standards and protocols
Standards compliance
• IEEE 802.1p/Q VLAN Tagging
• IEEE 802.3 10BaseT
• IEEE 802.3u 100BaseTX
• IEEE 802.3x Flow Control
• IEEE 802.3z 1000BaseSX/LX
Protocol support
LDP
• RFC 5036 LDP Specification
MPLS
• RFC 3031 Multiprotocol Label
Switching Architecture
• RFC 3032 MPLS Label Stack
Encoding
• RFC 4379 Detecting Multi-
Protocol Label Switched
(MPLS) Data Plane Failures
Differentiated services
• RFC 2474 Definition of the
Differentiated Services Field
(DS Field) in the IPv4 and
IPv6 Headers
• RFC 2597 Assured
Forwarding PHB Group
• RFC 2598 An Expedited
Forwarding PHB
• RFC 3140 Per Hop Behavior
Identification Codes
TCP/IP
• RFC 768 User Datagram Protocol
• RFC 1350 The TFTP Protocol
(Revision 2)
• RFC 791 Internet Protocol
• RFC 792 Internet Control
Message Protocol
• RFC 793 Transmission Control
Protocol
• RFC 826 Ethernet Address
Resolution Protocol
• RFC 854 Telnet Protocol
Specification
• RFC 1812 Requirements
for IPv4 Routers
PPP
• RFC 1332 PPP Internet Protocol
Control Protocol (IPCP)
• RFC 1661 The Point-to-Point
Protocol (PPP)
• RFC 1989 PPP Link Quality
Monitoring
• RFC 1990 The PPP Multilink
Protocol (MP)
ATM
• RFC 2514 Definitions of
Textual Conventions and
OBJECT-IDENTITIES for ATM
Management, February 1999
• RFC 2515 Definition of Managed
Objects for ATM Management,
February 1999
• af-tm-0121.000 Traffic
Management Specification
Version 4.1, March 1999
