Audiovox Rampage ACD95 User Manual
Page 3
128-6566
3 of 20
3
3
3
3
3
INSTINSTINSTINSTINST
ALLALLALLALLALL
AAAAA
TTTTT
ION INSTRUCION INSTRUCION INSTRUCION INSTRUCION INSTRUC
TTTTT
IONSIONSIONSIONSIONS
4. Mount the new radio assembly to the dashboard or center console using the
reverse procedure of step 1.
z
THE AMPLIFIERS IN THIS RADIO ARE ONLY DESIGNED FOR USE WITH 4 SPEAKERS.
z
NEVER COMBINE (BRIDGE) OUTPUTS FOR USE WITH 2 SPEAKERS.
z
NEVER GROUND NEGATIVE SPEAKER LEADS TO CHASSIS GROUND.
z
FAILURE TO WIRE CORRECTLY MAY CAUSE DAMAGE TO THE RADIO.
CAUTION !
INSTALLATION DIAGRAM
(TYPICAL)
