6 Others
58
Specifi cations
Product Name LCOS Projector
Model Name LTX-500
Display Panel/Size
LCOS device *1 *2 /
0.7" (1920pixels x 1080pixels) x 3 (Total no. of pixels: Approx. 6.22million)
Projection Lens 2.0 x power zoom lens (1.4:1 to 2.8:1)(Zoom/Focus: Power)
Light-source Lamp 200 W Ultra-high pressure mercury lamp [Part No. : BHL5010-S]
Screen Size Approx. 60" to 200" (Aspect ratio: 16:9)
Objection Distance Approx. 1.8m to 12m
Color System NTSC, NTSC4.43, PAL, PAL-M, PAL-N, SECAM (Auto/Manual switch)
Analog Video Input Format 480i, 480p, 576i, 576p, 720p/50Hz, 720p/60Hz, 1080i/50Hz, 1080i/60Hz
Digital Video Input Format
480i, 480p, 576i, 576p, 720p/50Hz, 720p/60Hz, 1080i/50Hz, 1080i/60Hz,
1080p/24Hz, 1080p/50Hz, 1080p/60Hz, PC compatible signals (
P59)
Resolution 1920 dots x 1080 dots
Color Management Featured
Terminals
Video Input
（
VIDEO）
1-line, RCA pin jack x 1
1.0V(p-p), 75Ω
S-video Input
（
S-VIDEO）
1-line, mini DIN 4 pin x 1
Y：1.0V(p-p), 75Ω
C：0.286V(p-p), 75Ω(NTSC)； 0.3V(p-p), 75Ω(PAL)
Component Video Input
（
COMPONENT）
1-line, RCA pin jack x 3
Y：1.0V(p-p), 75Ω
C
B
/P
B
, C
R
/P
R
： 0.7V(p-p), 75Ω
HDMI Input
（
HDMI 1, HDMI 2）
2-line, HDMI 19 pin x 2(HDCP compliant) *3
PC Input 1-line, D-Sub 15 pin VGA
Trigger Output 12V 100mA
Power Requirements AC 110V-240V 50/60 Hz
Power Consumption 280W (Standby mode: 1W)
Operation Environment
Temperature: 5℃ to 35℃
Humidity: 20% to 80% (No condensation)
(Storage Temperature: -10℃ to 60℃)
Installation Height Below 1524m
Dimensions
(Width x Height x Depth)
365mm X 167mm X 477.5mm
Mass 11.0Kg
Accessories (See P13)
*1 LCOS is the abbreviation for Liquid Crystal On Silicone.
*2 LCOS devices are manufactured using extremely high-precision technology. Pixel effectiveness is 99.99%. Only 0.01% or
less of the pixels are either missing or would remain permanently lit up.
*3 HDCP is the abbreviation for High-bandwidth Digital Content Protection system.
The image of HDMI input terminal may not be displayed due to HDCP specifi cation change.
●
Design and specifi cations are subject to change without prior notice.
●
Please note that some of the pictures and illustrations may have been abridged, enlarged or contextualized in order to aid
comprehension. Images may differ from the actual product.
