Yetter 2967-082 Residue Managers - Manual (Page 8)

8
YETTER MODEL 2965 & 2967
2965 Trashmaster and 2967 Residue Manager
The 2965 Trashmaster is a smooth disc furrowing attachment for planters which will cut a layer of
dirt and residue in front of the planter unit to leave a clear fresh path for the planter opener discs.
The 2965 Trashmaster is designed to move dirt and residue out of the path of the planter opener.
The 2967 Residue Manager is designed to work in heavy residue situations especially where
minimum soil movement is required. Depending on conditions and objectives, the 2967 Residue
Manager can be set shallow with the teeth only engaged in the residue so as to clear heavy
residue with minimal soil disturbance. Residue Managers are not recommended when surface
application pre-plant herbicide is used prior to planting.
OPTIONAL EQUIPMENT FOR TRASHMASTER & RESIDUE MANAGER
Model No. Description
6000-160 Light duty spring used only w/model 2965-015 and 2967-015.
2960-126 Heavy-duty down pressure spring package used on the 2965-015 and 2967-015.
2967-455 Residue Manager Wheel Cleaner
2967-081 Residue Manager for John Deere Screw Adjust Bracket
INSTALLATION
The universal model that fits on JD 7200/1700 series planters can be mounted two ways (See
Figure 1). The front set of holes is to mount these models on planter units with light duty or heavy
duty cast lower parallel arms. If the front set of holes is used, assemble two 1/2 bolts, 1/2” x 3-
1/2”, to the upper and lower rear holes on the mounting bracket using 1/2” locknuts. NOTE: Do
not over-tighten. The rear set of holes is for planter units with heavy-duty welded lower parallel
arms. For this application the 1/2” x 3-1/2” bolts are not used.
MOUNTING ARRANGEMENTS FOR JOHN DEERE 7200/1700 SERIES
FOR HEAVY DUTY “WELDED” FOR LIGHT DUTY OR HEAVY DUTY CAST
LOWER PARALLEL ARMS & 14” LOWER PARALLEL ARMS
21” LONG PARALLEL ARMS ALSO: KINZE 2000 (1993-NEWER), 3000 &
JD7000, KINZE 2000 (PRE 1993) WHITE 6100, 8000, 9000
FIGURE 1
