SPECIFICATIONS
Main unit
FM tuner section
Tuning range
87.5 MHz to 108 MHz
Usable sensivity (IHF)
13.2 dBf
Antenna
75 ohms (unbalanced)
AM tuner section
Tuning range
530 kHz to 1710 kHz (10 kHz
step)
531 kHz to 1602 kHz (9 kHz step)
Usable sensitivity
350 µV/m
Antenna
Loop antenna
Amplifier section
Power output
12 W + 12 W (65 Hz – 20 kHz,
THD 1%, 6 ohms)
15 W + 15 W (1 kHz, THD 10%,
6 ohms)
Total harmonic distortion
0.15 % (10 W, 1 kHz, 6 ohms, DIN
AUDIO)
Inputs
VIDEO IN: 400 mV, adjustable
AUX IN: 400 mV, adjustable
MIC: 1.4 mV (47 k ohms)
Outputs
PHONES (stereo jack): accepts
headphones of 32 ohms or more
DIGITAL OUT (OPTICAL):
Disc player section
Signal format
NTSC
Supported discs
DVD video discs
12 cm (single-sided single-layer,
single-sided double-layer, double-
sided-double layer)
8 cm (single-sided single-layer,
single-sided double-layer, double-
sided-double layer)
Compact discs (CD-DA, video
CD)
12 cm and 8 cm discs
S2 video output
Y output: 1 Vp-p (75 ohms, sync
negative)
C output: 0.286 Vp-p
Video output
Video composit output
1 Vp-p (75 ohms, sync negative)
One RCA jack
Operating conditions
5˚C to 35˚C (41˚F to 95˚F)
Monitor section
Display
5.8-inch Active Matrix TFT LCD
color display
General
Power requirements
120 V AC, 60 Hz
Power consumption
80 W
Dimensions
260
Ч
324
Ч
355 mm
(W
×
H
×
D)
(10
1
/
4
Ч
12
7
/
8
Ч
14 in.)
Weight
9.8 kg (21 lbs 10 oz.)
Speaker system
Cabinet type
2-way, bass reflex (magnetic
shielded type)
Speakers
Woofer:
100 mm cone type
Tweeter
25 mm balanced dome type
Impedance
6 ohms
Output sound pressure level 87 dB/W/m
Dimensions
120
Ч
210
Ч
182 mm
(W
×
H
×
D)
(4
3
/
4
Ч
8
3
/
8
Ч
7
1
/
4
in.)
Weight
1.7 kg (2 lbs 9 oz.)
Specifications and external appearance are subject to change
without notice.
The word "BBE" and the "BBE symbol" are trademarks of BBE
Sound, Inc.
Under license from BBE Sound, Inc.
DOLBY PRO LOGIC
Manufactured under license from Dolby Laboratories Licensing
Corporation.
"DOLBY" and "PRO LOGIC" are trademarks of Dolby Laboratories
Licensing Corporation.
COPYRIGHT
Please check the laws on copyright relating to recordings from
discs, radios or external tapes for the country in which the machine
is being used.
• Manufactured under license from Dolby Laboratories. "Dolby",
"Pro Logic" and the double-D symbol are trademarks of Dolby
Laboratories. Confidential unpublished works. ©1992-1997
Dolby Laboratories. All rights reserved.
• Manufactured under license from Digital Theater Systems, Inc.
US Pat. No. 5,451,942 and other worldwide patents issued and
pending. "DTS" and "DTS Digital Surround" are trademarks of
Digital Theater Systems, Inc. ©1996 Digital Theater systems,
Inc. All rights reserved.
