38 DSR Installer/User Guide Appendices 39
Appendix B: Technical Specifications
Server Ports
Number
DSR800: 8
DSR1161, 2161, 4160:16
Types PS/2 Keyboard, PS/2 Mouse
Connectors RJ45
Sync Types Separate horizontal and vertical
Plug and Play DDC2B
Video Resolution Local Port Maximum 1600 x 1280 @ 75Hz
Digital Port Maximum 1280 x 1024 @ 75Hz
Dimensions
Dimensions (HxWxD) DSR800: 1.72 x 17.00 x 8.075 in. 1U form factor (4.45 x 43.18 x
20.5 cm)
DSR1161, 2161,4160: 1.72 x 17.00 x 11.00 in. 1U form factor (4.45 x
43.18 x 27.94cm)
Weight 8lbs (3.6kg) without cables
Heat Dissipation 92 Btu/hr
Airflow 8 cfm (DSR1161, 2161, 4160 only)
AC-input power DSR800: 25W maximum DSR1161, 2161, 4160: 40W maximum
AC-input Range 100 to 240 VAC
AC-input current rating DSR800: 0.5A DSR1161, 2161, 4160: 1A
AC-input cable 18 AWG three-wire cable, with a three lead IEC-320 receptacle on
the power supply end and a country dependant plug on the power
resource end.
AC Frequency 50 - 60 Hz Auto Sensing
Temperature 32 to 104 degrees Fahrenheit (0 to 40 degrees Celsius) operating; -
4 to 158 degrees Fahrenheit (-20 to 70 degrees Celsius)
nonoperating
Humidity 10 to 95% noncondensing
Agency Approvals USA (UL, FCC), Canada (cUL, ICES-003), Japan (VCCI), Australia
(C-Tick), European Union (CE), Meets Class A limits for emmissions,
additional approvals may be pending
Configuration Port
Number
1
Type Serial RS232
Connectors DB9 Male
Network Connection
Number
1
Type Ethernet: IEEE 8023, 10 Base-T, Fast Ethernet: IEEE 802.3U,
100BaseT
Connector RJ45
User Consoles
Type
PC running Windows NT or 2000 OS and DSR console application
Minimum Configuration-300MHz Pentium III, 64Mb RAM, 100BaseT
NIC, XGA Video
Recommended Configuration-450MHz Pentium III , 128Mb Ram,
100BaseT NIC, SXGA Video
Local Port
Number
1
Type PS/2 and VGA
