Tuff Country 14058 - GM 07-13 Suburban / Tahoe 1500 4wd 4 lift kit User Manual
Page 4
4. Working on the driver side, remove the ABS line from the
OE upper control arm. The hardware maybe discarded.
Carefully remove the bracket from the ABS line and brake
line and set aside. Repeat procedure on the passenger side.
5. Working on the driver side, remove the sway bar end link
from the sway bar and lower control arm. Save the end link
and hardware. Repeat procedure on the passenger side.
6. Working on the driver side, remove the outer tie rod from
the OE knuckle. Save the hardware. Special note: Using a
hammer and striking the knuckle will help break the tap-
per. Take special care not to damage the outer tie rod
dust boot during removal. Repeat procedure on the pas-
senger side.
7. Working on the driver side, remove the lower hardware
securing the strut to the lower control arm. The hardware
may be discarded. Repeat procedure on the passenger side.
