Abocom UBT1000H User Manual
Page 3
SPECIFICATION
Standard
Bluetooth 1.1
Host Interface
USB1.1
Antenna
Built in the card
LED Indicator
Power: Orange LED
Frequency Range
2.4000-2.4835 GHz
Number of Selectable
Channels
79 channels
Data rate
Up to 723 Kbps
Typical Range
Devices connect for access and data sharing within ranges up to 320 feet
(100 meters)
Security
Data encryption up to 128-bits
RF Technology
Frequency hopping spread spectrum(FHSS)
Topology
8 devices
point-to-multipoint
Transmitter Power
Output power meets Class 1 requirements_15dBm MAX
Physical Specifications
Weight: 10 g
Dimension: 69.53 (L) X 26.68 (W) X 9.19 (H) mm
Power Requirement
Normal Operation: 5V DC, 200mA (Max)
Environment Specifications
Operating Temperature: 0~45℃ ambient temperature
Storage Temperature: -20~45℃ ambient temperature
Operating humidity: 90% maximum (non-condensing)
Storage humidity: 90% maximum (non-condensing)
Supported OS
Windows98/ME/2000/XP
Sensitivity
-77dBm
Distance
100 M
EMC Certification
FCC Part 15 in US
EN300328 and EN300826 (EN301489-17) in Europe
