Spyder Auto Crystal Headlight - Manual (Page 2)

Open the hood of the vehicle and remove the Engine
cover using a panel popper. Then Remove the head-
lights and corner lights from the car. There should
be two pins that holds the headlight, twist out and
pull up to remove the pins.
To remove the grille, there is one center bolt, use a
10mm to remove the bolt. Using a phillip screw-
driver, and remove the ends of the grille. As shown
on the picture, use the phillip and turn counter-
clockwise to unsnap. There is four screws on the
grille.
Carefully remove the side clips from the grille, once
they are off, remove the grille and put it aside.
Remove the Bolt on the bottom of the headlight
frame where the corner bumper light is located.
Once you remove the bolt, attach the Headlight
bracket on the mount as shown on the arrow.
The bracket with the black holder should be up
right.
Transfer the High beam and Low Beam bulbs
from the orignal headlight to the Spyder head-
light.
Install the Spyder Headlight to the vehicle and
put the sockets back on the new headlight.
When installing the headlight, the bottom bolt
should snap onto the bracket the was installed
earlier. Once you have align the bolt, put the
pins back on, on the top end of headlight.
STEP:
