10
System Monitor
• From the "Text Display" screen, click the "Chart Display"
button (Fig. 6).
• Enter the desired minimum and maximum ranges in the
Y-Max and Y-Min boxes (Fig. 7). Click the Set Y-Axis
Min_Max button whenever a new value is entered.
• Click "Exit" to return to the previous menu.
• Continue clinking "Exit" to return to the main menu.
1700 1720 1740 1760
80
70
60
50
40
30
20
Fig. 7
68
%RH
Datafile.mdb
Save Data Run
Scan Rate
2 sec
10-28-2002
11:30:26
0 0 0 0 6 7 5
Y-Max 80
Y-Min 20
Set Y Axis Min-Max
Clear Chart
Exit
Text Display
Angular Display
