Sper Scientific 850068 Hybrid Powered Environmental Meter - Manual (Page 17)

- 17 -
Thermocouple Temperature
Measurement
This procedure requires an optional Type-
K thermocouple probe.
1. Press POWER to turn the meter on.
2. Ensuring correct polarity (+ –), carefully
plug any Type-K thermocouple probe
into the Temperature Thermocouple
Input Port at the top of the meter.
Temperature differences between the
probe and the meter may cause
inaccurate results. Allow a few minutes
for the probe and meter to adjust to
ambient temperature.
3. Continuously press FUNCTION until
the meter displays the temperature
measuring unit (°C, °F).
4. Press °C/°F to select between a
Celsius (°C) and Fahrenheit (°F)
temperature reading.
5. Make contact between the thermo-
couple sensor probe and the object you
want to measure.
6. The meter measures
the temperature of the
object and displays the
value.
MEASUREMENT PROCEDURES
