• 7 •
Powering a 12v DC Device: 8.2
The jump starter is a power source for all 12v dC accessories that are
equipped with a 12V accessory plug. Use it for power outages and fishing or
camping trips. Estimated usage time is listed in the chart below.
Make sure the device to be powered is OFF before inserting the 12v dC
accessory plug into the 12v dC accessory outlet.
Ensure that the battery clips are securely clipped on the storage holders. 1.
Open the protective cover of the dC power outlet on the side of the 2.
jump starter.
Plug the 12v dC device into the dC power outlet, and turn the 12v dC
3.
device on (if required).
If the 12v dC device draws more than 15A or has a short circuit, the
4.
internal circuit breaker of the jump starter will trip and disconnect the
power to the device. disconnect the 12v dC device. The breaker will
automatically reset after an overload occurs.
The dC power outlet is wired directly to the internal battery. Extended
operation of a 12v dC device may result in excessive battery drain. Recharge
immediately after unplugging the 12v dC device.
Appliance type Estimated Wattage Estimated Usage time
Cell Phone 4 watts 36 hours
Fluorescent Light 4 watts 36 hours
Radio, Fan 9 watts 16 hours
depth Finder 9 watts 16 hours
Camcorder, vCR 15 watts 9.6 hours
Electrical Tool 24 watts 6 hours
Electrical Cooler 48 watts 3 hours
Car vacuum, Air Compressor 80 watts 1.8 hours
nOtE: Estimated run-times. Actual time may vary. Times are based on the
internal battery being fully charged
Using the Built-In Light
8.3
Position the jump starter on a flat, stable surface near the intended 1.
work area.
Ensure that the battery clips are securely clipped on the storage holders.
2.
Press the Power Switch to the LIgHT position. 3.
The jump starter light will turn on and illuminate your work area. 4.
Press the Power Switch to the OFF position. 5.
Charge the jump starter as soon as possible after using the built-in light. 6.
