5
No meter reading. Clips not making good contact. Rock clips back and forth for a better
connection.
Charger will not turn on AC outlet is dead. Plug in a lamp to check
when properly connected. for voltage.
Poor electrical connection. Check connections rock back and forth.
Noise from charger even when Transformer Hum. Normal condition no solution necessary
not hooked to the battery. Charger is okay.
Clicking noise from charger. Circuit breaker cycling. May be in the wrong position.
Battery is defective. Have battery checked.
Severely discharged battery but Allow charging to continue until battery has a
otherwise a good battery. chance to recover sufficiently to take a charge.
If more than 20 minutes, stop charging and
have battery checked.
Reverse battery connections. Shut off charger and correct lead connections.
The approximate time required to bring a battery to a full charge state depends upon the number of ampere hours (AH’s) depleted from
the battery. AH’s are determined by multiplying the number of hours time the number of amps supplied by the battery to the load. For
example- If a load was connected to battery which drew 7 amperes for a period of five hours, the battery will have supplied 35 AH. The
approximate recharge time would be calculated by dividing 35 AH depleted from the battery, by the ampere charge rate of the charger.
To allow for tapering of the charge rate add 25% to the charge time.
A hydrometer reading of the specific gravity of the electrolyte (fluid) of a battery in good condition should be between 1.25 and 1.285.
When a battery reaches 80-85% of full charge, bubbles will appear on the surface of the fluid. As the battery nears full charge, bubbling
will become more vigorous.
Storage: Store the battery charger in a dry area.
PROBLEM POSSIBLE CAUSE SOLUTION
LIMITED WARRANTY
SCHUMACHER ELECTRIC CORPORATION, 801 BUSINESS CENTER
DRIVE, MOUNT PROSPECT, ILLINOIS, 60056-2179 MAKES THIS LIM-
ITED WARRANTY TO THE ORIGINAL PURCHASER AT RETAIL OF THIS
PRODUCT. THIS LIMITED WARRANTY IS NOT TRANSFERABLE.
Schumacher Electric Corporation warrants this battery charger for five years
from date of purchase at retail against defective material or workmanship. If
such should occur, the unit will be repaired or replaced at the option of the
manufacturer. It is the obligation of the purchaser to forward the unit to-
gether with proof of purchase, transportation and / or mailing charges pre-
paid to the manufacturer or its authorized representative.
This limited warranty is void if the product is misused, subjected to careless
handling, or repaired by anyone other than the factory or other authorized
factory representative. The manufacturer makes no warranty other than this
limited warranty and expressly excludes any implied warranty including any
warranty for consequential damages.
This is the only express limited warranty and the manufacturer neither as-
sumes nor authorizes anyone to assume or make any other obligation to-
wards the product other than this express limited warranty. The manufac-
turer makes no warranty of merchantability or fitness for purpose of this
product and expressly excludes such from this limited warranty.
Some states do not allow the exclusion or limitation of incidental or conse-
quential damages or length of implied warranty so the above limitations or
exclusions may not apply to you.
This warranty gives you specific legal rights, and you may have other rights
which vary from state to state.
L. CHARGE PERIOD
M. INDICATIONS OF A FULLY CHARGED BATTERY
N. TROUBLESHOOTING
The battery charger is designed to work automatically. However, if a problem does occur, check the following:
