Step 9
Connect the longer green earth ground wire to the clamp tab.
Step 10
Mount the drain ground clamp to the metal drain tail stock as close to the sink as possible.
Step 11
Connect the brass plated end (black sleeved) of the green Grounding Isolation Wires (BB) to the drain ground
clamp tab (V).
Step 12
Connect the ring terminal on the green Grounding Isolation Wires (BB) to the stud with the hex nut (DD).
Continue fastening with lock washer (CC) and hex nut (F). [NOTE: For single-hole mounted faucets remove
the ring terminal wire with wire cutters.]
Step 13
Connect the other end of the green Grounding Isolation Wires (BB) to the tab grounding spacer(G).
Step 14
See battery compartment installation instructions below. Then connect the battery power connector wires
together. Test the black sensor wire with your fingers. There will be a clicking sound coming from the valve
control module indicating that the faucet is installed properly.
Step 15
Connect the black sensor wire to the sensor washer (I).
Step 16
Connect the water supply hoses (L) to the valve stops. Turn on the hot and cold water supply and test faucet.
NOTE:
· If the optional 6” extension hose (J) is used between the valve control module (K) and the faucet shank
connection (to lower the unit down for accessibility), the rubber washer (R) is not required.
· If this is an AC adapter installation, skip “Battery Compartment Installation” and use instructions
supplied with the AC adapter.
Battery Compartment Installation
1. Remove battery compartment cover by unscrewing the two Phillips screws. Inside the battery compartment
(N) there are two large screws and anchors (O). Place the battery compartment (N) in a convenient location
ensuring easy access.
2. Secure to wall using screws and anchors (O) or double-sided tape (P).
3. Install four (4) “D” cell alkaline batteries (Q). Replace cover on battery compartment. Connect battery box
connector to valve power connector. Once power is established, you will hear a clicking sound when you
place your hand under the faucet.
4. Turn water supply on. The water will automatically come on when you place your hand under the faucet.
The water will stay on for a maximum of 15 seconds as long as your hands are under the faucet, and
moving. The water will shut off after you remove your hands from the sensing zone or water stream.
5. Verify water supply connections are not leaking.
Setting Water Temperature Mix
1. There is a temperature dial on the mixing valve (M). Use a screwdriver to loosen the screw on the dial.
[To add hot water, turn the knob to the right or to the left to add cold water. ]
2. Once you have the desired water mix temperature, lock the control knob in place with a screwdriver.
3. There is a temperature adjustment on the optional thermostatic mixing valve (FF). Use an allen wrench to
turn adjustment screw to add hot or cold water.
