IMPORTANT - DO NOT USE PIPE DOPE OR TEFLON TAPE FOR
ANY FAUCET OR SUPPLY CONNECTIONS!
Step 1
Attach both threaded studs (D) to the bottom of the semi-assembled cover plate.
Step 2
Guide the semi-assembled faucet spout through the 3-hole 4” or 8” center set in counter or
sink.
Step 3
Finish securing the cover plate from underneath by placing the two metal washers (E) on to
each of the threaded studs. Secure with hex nut (F) and hex nut (DD).
Step 4
Secure the spout by using the following components in sequential order:
a. Tab grounding spacer (G) (brass washer needs to be on top)
b. Brass mounting nut (H)
c. Sensor wire connection washer (I) [IMPORTANT: Make sure this washer’s tab is
rotated 180° from the tab grounding spacer (G).]
d. Brass mounting nut (H)
Step 5
Connect the two 12” supply hoses (L) to the mixing valve (M). Place the rubber washer (R) into
the mixing valve’s brass nut fitting (as shown) and then tighten to bottom of the valve control
module (K).
Step 6
Connect the earth ground wire (U) to one side of the U-tab. Then connect the yellow sleeved
drain ground connector, located on the Grounding Isolation Wires (BB), to the other side of the
brass U-tab.
Step 7
Hand tighten the valve control module assembly to the faucet shank.
NOTE: Make sure the black rubber washer is in the white plastic nut before connecting the
valve control module to the faucet shank.
Step 8
Mount the earth ground clamp to the cold water supply pipe.
Instructions continued on reverse side
Installing Your New Faucet
3
