TRACTOR OPERATION
END OF SEASON STORAGE
SERVICE
CLEAN THE ENTIRE MACHINE AND
ENGINE
Thoroughly clean the machine and engine then
blow dry with 50 PSI compressed air.
ENGINE SERVICE
1. Refer to the engine manufactures manuals
for specific recommendations and proce-
dures.
MACHINE SERVICE
1. Lubricate all grease point as shown in the
Lubrication Section.
2. Lubricate all linkage pivot points.
3. Spray exposed cabled with a fluid lubricant
to prevent binding and rust.
4. Examine drive belt and chain for damage
and replace as required.
5. Check the condition of all shields and
replace as required.
6. Check safety decals and replace as required.
7. Check all bearings and gear box for bearing
condition. Replace any loose bearings.
SPECIFICATIONS
ENGINE
Honda - GXV390K1 13.0 HP
FUEL TANK
1.0 US Gallon
TRANSMISSION
Tuff Torq Model K62
Hydrostatic
Infinite variable control
Oil - 2.5 liters of 10W30 Class CD motor oil
GROUND SPEED
0 - 4.2 mph
WEIGHT
440 Lbs.
DIMENSIONS
42" W x 45" H x 76" L
36" Maximum working width
DRIVES
Engine mounted clutch/brake
Heavy duty bevel gearbox with sealed bearings
B76 main drive belt
#50 o-ring final drive chain
TIRES
Rear = 18 x 6.5 heavy 4-Ply lugged
CONTROLS
Variable speed control lever
Swing control lever
Transport release lever
FRAME
Heavy formed tube mainframe, Tractor
12 gauge fabricated mainframe, Tiller
12
