MULTI-TASKER

7

Example:

If one MT104-102 card is in slot #2 of unit 3:

To send command

[VERC2U3],

the Multi-

Tasker™ Enclosure will return feedback as:

MT104-102 690-0158-003

2. [C]

This command receives the status of the card.

Command Format: [CnUi]

Cn = card id (n = 1 to 19)
(1-8 for MT100-101 or 1-4 for MT100-106)
Ui = unit id (i = from 0 to 9) (refer to the MT100-
100 user’s guide for explanation)

Example:

If one MT104-102 card is in slot #2 of unit 3 with
input 1 ON:

To send command

[C2U3],

the Multi-Tasker™

Enclosure will return feedback as [

On1C2]

or

[

On1ER03C2]

if there is error number 3 (see error

code list).

If there is no card in slot #2 of unit 3, sending the

[C2U3]

command will not return any feedback.

ERROR CODES

ER01: CPU Error

This error indicates that the CPU is not working
properly.

ER02: I²C Communication Error

This means that the communication between the
MT104-102 card and its serial device has failed.

ER03: RS485 Communication Error

This type of error is a communication error
between the MT104-102 card and the controller of
the Multi-Tasker™ Enclosure.

[CiS]

This command saves card status, such as Input
number connected to the output, as a default
configuration of the card.

3. [ON]

This command enables one input of a single card
or a group of cards.

[ONmCnUiS]: for a single card

This command enables input “m” and disables all
other inputs.
Default when plugged in = Input 1 is ON
m = Input number (m = 1 to 6)
Cn = Card ID No. (n = slot # from 1 to 19)
(1-8 for MT100-101 or 1-4 for MT100-106)
Ui = Unit ID number (i = 0 to 9)
S = saves command to memory

Example:

If all of the inputs on the MT104-102 card are
OFF and the card is in slot #5 of unit 3:
1)

[ON1C5U3

]: Turns ON only input 1 of the

MT104-102 card.
2)

[ON3C5U3

]: Turns ON only input 3 (input 1 is

now OFF).

[ONmGkUiS]: for a group of cards

This command enables input "m" for each card in
group "k" of unit "i".
m = card input (m = # from 1-6)
Gk = group number (k = # from 1-9)
Ui = unit number (i = # from 0-9)
S = saves command to memory

Example:

[ON1G1U1]: Turns ON input 1 for each card in
group 1 of unit 1.

[ON…P]: sets path

This command will set the path for the output, but
it is not active until the switch command is
executed ([SW]). Commands ending in "P" are
not executed immediately. The path for outputs
on multiple cards or the same card can be
loaded.
Command Format:

[ONmCnUiP]

m = input number (m = 1 to 6)
Cn = card ID no. (n = slot # from 1 to 19)
(1-8 for MT100-101 or 1-4 for MT100-106)
Ui = Unit ID number (i = 0 to 9)
P = path
