MULTI-TASKER
9
[SW]
The system will return feedback as OK if the unit
ID is zero.
6. [WR]
This command groups multiple cards in the
MT100-100 Enclosure. Each unit contains a
maximum of nine groups.
Command Format: [WRCn…GkUi]
n = card ID No. (n = slot # from 1 to 19)
(1-8 for MT100-101 or 1-4 for MT100-106)
k = group number (k = # from 1-9)
i = unit number (i = # from 0-9)
Example:
To group card #1, 2, and 3 as group 5 of unit #1,
send the [WRC1C2C3G5U1] command. After
executing this command, cards 1, 2, and 3 of unit
1 will be grouped together as group 5.
7. [CLR]
This command clears the members for a single
group or for all nine groups.
Command Format: [CLRGkUi]
k = group number (k = # from 1-9)
i = unit number (i = # from 0-9)
Example:
a) To clear group #1, send the [CLRG1U1]
command. This command clears the members
for the specified group only.
b) To clear all groups of unit 1, send the
[CLR G[U1] command.
8. [G]
This command is used to request group data.
With the command, the user can identify which
input or output of a particular group is on.
Command Format: [GkUi]
k = group number (k = # from 1-9)
i = unit number (i = # from 0-9)
Example:
If group 1 has DA Cards with output 1 and 2 on,
while group 2 has SW Cards with input 2 on:
[G1]: will return feedback as [On12G1].
[G2]: will return feedback as [On2G2].
9. [RD]
This command displays the members in each
group. Command Format: [RDGkUi]
k = group number (k = # from 1-9)
i = unit number (i = # from 0-9)
member = C1 - C19 (card 1 to 19)
(1-8 for MT100-101 or 1-4 for MT100-106)
Example:
To read member data for group 1 of unit 1, send
the [RD] command. The system will return
feedback as C1C2C3 G5U1.
10. [SIGCi]
This command checks if signal on input is
present. Command format [SIGCi]
Example:
If MT 104-102 is in slot#4. Feedback for
command [SIGC4] –0, it means that signal on
input1 is not presents.
11. [HELP]
This command displays available for RS-232
control commands.
