Rear Shock
I d
d t Rid H i ht Adj t
t
Independent Ride Height Adjustment
Adjustable Platform on rod end in swing arm
Adjustable Platform on rod end in swing arm
y
Currently set in middle of range
y
Loosen lock nut and adjust
y
Loosen lock nut and adjust
y
1 turn ≈ 1 mm of ride height adjustment
y
1” wrench to loosen locknut
Ride Height Adjustment
Locknut
Ride Height Adjustment
Exposed thread length not to
exceed .472 (12 mm)
Clevis
