Rear Shock
C
i Adj t E l ti Compression Adjuster Explanation
€
High-Speed Adjuster ( Knob)
€
High Speed Adjuster ( Knob)
y 25 Clicks of Adjustment
y Clockwise is Stiffer y Clockwise is Stiffer
y Tune for Bumps and Landings
y
Blue knob will rotate with black knob
y No tools needed use hand
More firm
(clockwise)
y No tools needed – use hand
y Setting Nomenclature:
○ “0” = Full Soft/Fully Softened Compression
○ “+25” = Full Stiff / Full Clockwise Stop
( )
○ +25 = Full Stiff / Full Clockwise Stop
○ Always count settings from “0”
