Penske Racing Shocks 8975-DRAG - Manual (Page 15)

PS-8975-DRAG (Double Adjustable) 2010/2011
15
Parts List:
KEY PART NUMBER DESCRIPTION
2 BD-75XCO BODY, 7500 C/O
3 RR-06 WIRE RING, .0625 WIRE DIAMETER X 1.900"
4 BC-75TV-DA BODY CAP, 7500 DOUBLE ADJUSTABLE
5 OR-2133-B O-RING, BUNA, 70 DUROMETER
6 CO-75HV COLLAR, 7500 SERIES HEAD VALVE
7 PI-75HV-3PORT PISTON, 7500 SERIES HV 3 PORT
8 OR-2029-B O-RING, BUNA, 70 DUROMETER
9 VW-120004-625 WASHER, 1.200 X .004 X .625 VALVE
10 VS VALVE STACK, COMPRESSION AND REBOUND
11 SC-75HV-DA SCREW, 7500 DA HEAD VALVE
12 VW-75020-625 WASHER, .750 X .020 X .625 VALVE
13 MR_73 METERING ROD, 7300
14 OR-2008-V O-RING, 5 MM X 1 MM, VITON
15 PI-75-DA PISTON, 7500 DOUBLE ADJ FLOATING
16 OR-2008-V O-RING, VITON, 70 DUROMETER, BROWN
17 OR-4221-B QUAD RING, BUNA, 70 DUROMETER
18 NE-75X-DA NEEDLE, 7500 DOUBLE ADJUSTABLE
19 RS-73 REBOUND SCREW, 7300 HEX
20 BA-093-ST BALL, 3/32 STEEL
21 SP-36 SPRING
22 FT-75X-DA FITTING, 7500 DOUBLE ADJUSTABLE
23 VW-75-DA WASHER, 7500 DOUBLE ADJUSTABLE
24 OR-2011-B O-RING, BUNA, 70 DUROMETER
25 OR-3MM X 1.5MM-V O RING, 3MM X 1.5MM, VITON
26 SC-75-DA SCREW, 7500 DA HOL-LOCK SOCK 500-20
27 IU-75NV INFLATION SEAL SCREW
28 OR-2010-B O-RING, BUNA, 70 DUROMETER
29 SC-75 SCREW, BUTTON HEAD 6/32 X 1/8"
30 OR-3.5MMX1MM O-RING, VITON
31 DO-18 ROLL PIN, 1/16 X 1/2
32 RR-16 RET RING, 1.025 SPIROLOC, STAINLESS
33 MO-8T MONOBALL, .500 ID X 1.00 OD
34 SB-89 SHAFT BEARING, 8900
35 SL-09 SHAFT WIPER, .625 POLY (BLUE)
36 BU-10DU04 BUSHING, DU .625 X .250
37 OR-2114-V O-RING, VITON, 75 DUROMETER
38 OR-2221-B O-RING, BUNA, 70 DUROMETER
