MBRP S7110 - Manual (Page 2)

S7110 © 09/10 PAGE 2 OF 4
2008-2010 DODGE CHALLENGER SRT8®
Removal of Stock System:
1. Apply a penetrating lubricant liberally to all exhaust fasteners,
hangers and rubber insulators.
2 Remove the nuts from the flange on the rear of the muffler (on the
driver side). Remove the rubber insulator. Refer to Figure 1.
3. Remove the two factory hangers by removing the hardware on the
driver side. Remove the driver side muffler and tail pipe. Refer to
Figure 2.
4. Loosen the band clamps on the factory exhaust located in front of
the X-pipe. Refer to Figure 3.
5. Remove the two factory hangers by removing the hardware on
the passenger side. Remove the rubber isolator behind the dual
muffler. Remove the passenger side exhaust from the X-pipe back.
Refer to Figure 4.
Figure 1
Figure 2
Figure 3
Figure 4
