IC2317 © 10/13 PAGE 2 OF 4
2013-14 Ford Focus ST
Removal of Stock System:
1. Loosen the air charge hose clamp on the throttle body.
Refer to Figure 1.
2. Remove the under car engine cover.
Refer to Figure 2.
3. Remove the front lower valance panel (optional, but it gives easier access
to the intercooler connections).
4. Remove the nut and bolt securing the hot side intercooler pipe.
Refer to Figures 3 and 4.
5. Loosen the air charge hose clamp connections at the intercooler and the
turbocharger.
Refer to Figures 5, 6 and 7.
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
