Removal of Stock System:

Separate the stock exhaust system at the slip joint by the

muffler. Remove the rear exhaust from the rubber hangers and
remove the system from under the truck.

Using a 15mm socket or wrench, remove the two (2) bolts at the

turbo flange and remove the stock down pipe.

Installation of

MBRP Inc.

Performance Exhaust:

Install the Down Pipe starting from behind the cross

member and place it in the same position as the stock down
pipe. Place the hanger into the OEM rubber insulator and
attaching the flared end to the turbo using the supplied M10
x 60mm Bolts. Do not fully tighten until all components are
in place. Refer to Figures 1 & 2.

Install the 42” Extension Pipe over the Down Pipe. The

42” Extension Pipe may require cutting to accommodate
vehicles other than the Quad Cab long bed. (Installation
tip: Temporarily hang the Muffler and the 4” Hanger
Clamp in place using the two OEM rubber hangers and
measure from the Muffler to the Down Pipe to determine
the length required.) Refer to Figure 3.

Figure 1

Figure 2

Figure 3
