S6006 © 06/09 PAGE 2 OF 5
Removal of Stock System:
1. Apply penetrating lubricant liberally to all exhaust fasteners,
hangers and rubber insulators.
2. Using a 15mm socket or wrench, disconnect the factory exhaust
system at the four bolt flange located behind the catalytic
converter. If the vehicle is not equipped with a catalytic converter
disconnect the four bolt flange located approximately under the
passenger seat. See Figure 1.
3. Remove the exhaust system from the rubber insulators and
remove from under the vehicle. If a hoist is not available for use
it may be necessary to cut the tail pipe behind the muffler for
removal of the system.
4. Unbolt the OEM hanger from the transmission and remove. Do
not discard the hanger as it is required for the installation.
See Figure 2.
5. Loosen the factory band clamp and remove the stock front pipe.
See Figure 3. Do not discard the band clamp as it is
required for the installation.
Installation of MBRP Inc. Performance Exhaust:
1. Install the Front Pipe onto the factory down pipe using the band
clamp removed previously. Do not fully tighten to allow for
adjustment. See Figure 4.
Figure 1
Figure 2
Figure 3
Figure 4
