1. Measure 20” across from the inside surface of the passenger
side bed rail. Mark this location along the rail. This will be the
approximate centerline of the Stack once installed. Refer to
Figure 1.
2. Slide the Band Clamp (from Stack kit – purchased separately)
over the Stack. Wedge the Stack Mounting Bracket between
the Band Clamp and Stack and adjust to the bed rail height and
tighten the Band Clamp slightly. Make sure the Stack is vertical,
the Stack Mounting Bracket is flush against the bed rail and
centered on the measurement made in Step 1. Trace a circle
around the base of the Stack and center punch the circle’s
center. Verify that the center punch hole is in line with your
existing exhaust and adjust accordingly. This will be the
center line of your Stack.
3. Align the Stack centered on the mark you made in Step 2. Mark
the bolt hole location of the Stack Mounting Bracket onto the
front rail of the bed. Center punch the marks and drill holes to
accommodate the 3/8” hardware. Refer to Figure 2.
4. Loosely attach the Stack Mounting Bracket to the front of the
truck bed using the 3/8” hardware supplied. Set the Stack up in
the bed and loosely attach it to the Stack Mounting Bracket.
Make sure the Stack is vertical and in the desired position.
Refer to Figure 3.
Figure 1
Figure 2
Figure 3
