SPECIFICATIONS
Circuit All discrete transistor used only for gain
EQ is passive - no transistors in EQ
Transformerless
Regulated low noise supply
Frequency response ±0.5 dB 10Hz to 60KHz
THD >.04%
Noise (w/ 80KHz filter) 0.25 mV (-70dB)
S/N ratio (Ref. 20V) @1KHz 99 dB
Input Impedance 20 k ohms
Output Impedance 50 ohms
Maximun Output +22 dBm (600 ohms)
+28 dBv (10,000 ohms)
EQ PASSIVE L / C / R
LF CUT 0 to -15 dB
LF BOOST 0 to +12 dB
FREQUENCIES 20, 30, 60, 90, 120
HF BOOST 0 to +17 dB
FREQUENCIES 1K, 1.5, 2, 3, 4, 5, 8, 10, 12, 14, 16K
HF CUT 0 to -15 dB
FREQUENCIES 4K, 8, 12, 16, 20K
Power Consumption 12 watts
Size (1U) 19" x 1.75" x 10"
Shipping Weight 11 lbs
