Manley MONO VARIABLE MU LIMITER / COMPRESSOR 5670 MODELS - Manual (Page 5)

INSTALLATION
Please refer to the REAR PANEL section for a full layout of the rear panel of your
Mono limiter compressor.
1. Set the voltage change-over switch on the back of the unit to the voltage you
are using.
2. Be certain that the unit has a 1 Amp SLO-BLO (120 Volt operation) fuse.
3. Connect the input signal(s) to the 3 pin female XLR's on the rear panel. The
input XLR's are TRANSFORMER COUPLED balanced wired as follows:
PIN 1: GROUND
PIN 2: (+) POSITIVE GOING PHASE
PIN 3: ( - ) NEGATIVE GOING PHASE
4. Connect a 3 pin XLR cable to the male output XLR on the rear panel. The
output XLR is balanced and the pinout is wired as follows:
PIN 1: GROUND
PIN 2: (+) POSITIVE GOING PHASE
PIN 3: ( - ) NEGATIVE GOING PHASE
The output impedance is 600 Ohms.
5. Connect a standard IEC mains cable to the IEC mains socket on the rear
panel.
6. Check that the power is switched off on the unit.
7. Connect the IEC mains cable to a 50/60 Hz AC source of the proper selected
voltage.
8. Power up the unit and allow it enough time to stabilize before using (approx
15 to 30 minutes).
