Innovate Motorsports ST-12 User Manual
Page 4
4
2
The SuperTune-12 (ST-12)
Serial In/Out
Analog
Outputs
Rear View
Digital connection from
each individual LC-1ST
(wideband controller) to
the DB-15 connector
Variable
Potentiometer to
adjust the RPM signal
Inductive
Clamp input
Analog Inputs
Power Supply
On/Off switch
Program functions such as RPM, MAP,
Temperature, Duty Cycle, and analog inputs.
RPM calibration number can also be
programmed here.
LED indicates LC-1ST conditions
such as warming up, normal
operation, or error codes.
Push buttons trigger a Free Air
Calibration on the LC-1STs.
ON/OFF
switch
Front
View
