Fantasea Nano Ray Lighting Sets Instruction Manual 27110120 4
ii. Install the Nano Flash inside the flash housing
iii. Select the proper pre-flash program for your camera
iv. Test the water tight seal of the Nano Flash
d. Assemble the Blue Ray Double Tray-
i. If you own the Nano Double Ray Set (Cat. No. 2078), follow the Blue Ray
Tray instruction manual in order to assemble the Blue Ray Double Tray (Cat.
No. 2050).
ii. If you own the Nano Single Ray Set (Cat. No. 2076), which includes the Blue
Ray Single Tray (Cat. No. 2040), please skip to section “e”, as there is no
need to assemble the Blue Ray Single Tray.
iii. If you own an XL Stay Slot Tray (Cat. No. 2030), please refer to paragraph “4”
for special instructions regarding this tray.
e. Attach the Flex Arm to the Blue Ray Tray-
i. Follow the Flex Arm instruction manual in order to attach the Flex Arm to
the Blue Ray Tray.
ii. If you own the Nano Double Ray Set (Cat. No. 2078), attach both Flex Arms
included with the set to the Blue Ray Tray.
f. Mount the Nano Flash on the Flex Arm-
i. Follow the Nano Flash instruction manual in order to mount the Nano Flash
on top of the Flex Arm.
ii. If you own the Nano Double Ray Set (Cat. No. 2078), note that the Nano
Flash should be mounted on the left Flex Arm (when looking from the back
of the system), as the Nano Focus Light will be mounted on the Flex Arm
positioned to the right.
g. Attach the Fiber Optic Cable to the Nano Flash and Camera Housing-
Follow the Nano Flash instruction manual in order to attach the Fiber Optic Cable
to the Nano Flash and outside of the camera housing.
h. Mount the Nano Focus Light on the Flex Arm-
i. Follow the Nano Focus Light instruction manual in order to mount the Nano
Focus Light on the Flex Arm positioned to the right.
ii. If you own the Nano Single Ray Set (Cat. No. 2076), please skip to section “i”
as there is no Focus Light included with this set.
i. Mount your Camera Housing on the Blue Ray Tray-
Follow the Blue Ray Tray instruction manual in order to mount your camera
housing on the Blue Ray Tray.
