Fantasea Nano Ray Lighting Sets Instruction Manual 27110120 3
when accessory lenses are mounted on the housing lens port.
2. Nano Fiber Optic Cable- Although the Nano Flash features a slave sensor and is
capable of synchronizing with the camera internal flash without using any cables
in most diving conditions, a fiber optic cable ensures the best synchronization
between the camera internal flash and the Nano Flash at all angles and within
various diving conditions, especially when photographing in shallow clear water
with bright ambient light.
3. Blue Ray Tray- The Blue Ray Tray allows integrating different components in an
underwater photo system, including the camera housing, arms, strobes, lights,
lens holders and more. Made from anodized aluminum, this sturdy tray was
designed for optimal functionality and ease of operation. The Blue Ray Tray is
compatible with all compact digital housings.
If you own an XL Stay Slot Tray (Cat. No. 2030), please refer to paragraph “4” for
special instructions regarding this tray.
4. Flex Arm- The Flex Arm is a flexible arm made of rugged plastic polycarbonate
material, designed for attaching a flash, focus light or night dive to a tray. The
flexible design of the arm allows for the light or flash mounted on top of it to be
positioned within different angles and distances from the camera housing.
5. Nano Focus Light- The Nano Focus Light is a high intensity ultra compact
underwater LED light. It was designed as a modeling light and in order to better
enable the camera auto focus, especially when photographing in low light
conditions. The Nano Focus Light features a dim-out sensor which automatically
shuts off the LED light whenever a camera pre-flash is fired, thereby eliminating
a hotspot in the image, caused by the beam of the light.
6. Fantasea Pro Bag- A padded bag especially designed for secure storage and
transportation of all underwater photo system components.
3. Nano Ray Lighting Set Assembly Instructions
a. The Nano Ray Lighting Set should be assembled after the camera has been
installed inside the camera housing, the housing has been closed and its
watertight seal has been tested.
b. If making use of an accessory lens, it should be installed on the housing lens port
only after assembling the housing and the lighting set.
c. Prepare the Nano Flash-
Follow the Nano Flash instruction manual in order to:
i. Install fresh batteries in the Nano Flash
