Retrieving Codes
FAULT CODE DEFINITIONS FOR EEC-IV SYSTEMS (217 - 311)
59 Chapter 4
TEST
CODE CONDITION FAULT CODE DEFINITION
217 C DIS fault ignition system - coil #3
218 C Loss of Ignition Diagnostic Monitor (IDM)
signal/left side
219 C (Cars ONLY): SPOUT signal defaulted to
10° BTDC / SPOUT circuit open
221 C Spark timing error
222 C Distributorless Ignition System - loss of
right side ignition Diagnostic Monitor
(IDM) signal
223 C Distributorless Ignition System - loss of
dual plug inhibit (DPI) control
224 C Erratic IDM input to processor
224 C (Trucks ONLY): SPOUT circuit ground/coil
1, 2, 3 or 4
225 R Knock sensor fault during dynamic
response test
226 C (Cars ONLY): Ignition diagnostic Monitor
(IDM) signal not received
226 C (Trucks ONLY): Electronic Distributorless
Ignition System (EDIS) problem -
Crankshaft Position Sensor (CPS) problem
227 * Crank position sensor
232 C (Trucks ONLY): Electronic Distributorless
Ignition System (EDIS) Coil 1, 2, 3 or 4
circuit fault
233 * Spark angel pulse width error
238 C PCM detect coil 4 primary circuit failure
239 * Crank position signal received with engine
off
241 * EDIS to EEC processor ignition diagnostic
module pulse width transmission error
242 * Operating in DIS failure mode
243 * Secondary circuit failure
244 R Cylinder identification circuit failure
311 R Thermactor air system/fault during engine
run self-test
