1-4
1.7 TECHNICAL SPECIFICATIONS
Table 1-1 provides technical specifications for the MNVD.
Table 1-1 Technical Specifications
WEIGHT AND DIMENSIONS
Weight < 14.1 ounces (400 g)
Length
(with standard eyecup)
6.5 inches (16.5 cm)
Width 2.8 inches (7.1 cm)
Height 2.4 inches (6.1 cm)
POWER AND PERFORMANCE
Battery One 1.5V AA lithium battery
Battery Life 1 > 15 hours
Magnification 1x
Field of View 40° (± 2°)
Objective Focus 9.8 inches (25cm) to infinity
Diopter Adjustment +2 to -6
Immersion 1 meter for 30 minutes
Operating Temperature -60°F (-51°C) to 120°F (49°C)
Storage Temperature -60°F (-51°C) to 185°F (85°C)
1 Performance will vary depending on actual environmental and
atmospheric conditions.
