Cyron Lighting HTP2406W2 User Manual
Page 6
every time the outlet is switched on. In this mode, the system can only be
turned on from the controller by pressing the POWER button.
Possibilities _____
The controller is compatible with all Media Highlighter lights. System is
provided with 6 ports for easy connections to Media Highlighter Lightbars. For
the ultimate expandability, the system is equipped with a second output plug
that allows expanding the system with HTPR-RL ribbon lights or adding a
second hub for more Media Highlighter lights.
When expanding system, the power supply must be upgraded to
handle the total power usage of the system.
Specifications _____
Supply voltage range
100-240VAC, 50/60Hz
DC Supply voltage
12VDC
Peak power
HTP1506W2=15W, HTP2406W2=27W
Nominal power
HTP1506W2=7W, HTP2406W2=13W
Working Temperature
-20 to 60ºC
Standby power
0.5W
HTW202 Controller Specifications _____
Supply voltage range
9-24VDC
Current
9A peak via DC jack
6A continuous
Continuous output power
72W @ 12VDC, 140W @ 24VDC
Working Temperature
-20 to 60ºC
Common terminal
Anode
Standby power
0.5W
