Wiring
CYRON Vanishing Light is a low voltage system. With
the exception of Power supply input, all other wires are operating at
low voltages to minimize the risk of electrical shocks or fire hazards.
However, working with electrical devices has risks. Consult with
CYRON Technical Support or your qualified electrician for good
wiring practices. Here are few to keep in mind:
Never cut wires or modify the lighting system without
consulting CYRON team.
Secure all wires using zip ties, electrical staples or wire clips.
Additional finishing touches can be done with wire
management systems such Wiremold
®
.
Keep wires away from extreme heat, moving objects, strong
chemicals and any other conditions that will hinder the
integrity of the lighting system.
Estimate the distance between the lightbars. Use the extension cord if
lightbars are more than 8 inches apart. Additional extension cords (part
no. CL-EXT) are available from CYRON or by visiting
Maximum 4 extension cords per system.
CYRON staff may be able to help with custom solutions for systems
expanding beyond several lightbars and few extension cords.
General guidelines:
Do not connect more than six lightbars in series.
Do not use more than four extension cords per cluster of
lightbars connected in series.
Never exceed the power supply ratings. See specification table
below for ratings.
Various lightbar sizes can be combined in one system.
CLMW and CLFWs components can be combined to make
“Y” connectors.
20” expansion lightbar, Silver / Black
CL20W / CL20BW
12” expansion lightbar, Silver / Black
CL12W / CL12BW
Extension Cord, 3ft
CL-EXT
Pigtail cord, female connector
CON-CLFW
Pigtail cord, male connector
CON-CLMW
