5. SUNSHIELD
Open the sunshield on the monitor bag and secure the position by using the
velcro-backed strap. Remove protective film from monitor.
Adjust the monitor settings as needed by using the dials on the front of the monitor.
Brightness, Color and Contrast are adjustable.
8. WRIST or SHOULDER STRAP
To charge the battery, plug the battery charger cable into the battery cable from the
battery. Set the battery switch to the ON position (red LED down on switch). When
connected properly the LED on the charger will change from GREEN to RED. When fully
charged (after approximately 8 hours) the LED on the charger will go back to GREEN.
WRIST STRAP.
Place wrist in wrist strap on the back of the monitor bag and
tighten.
SHOULDER/NECK STRAP.
The strap doubles as a shoulder strap for
carrying the monitor or as a neck strap for hands-free viewing of the monitor.
7. BATTERY CHARGING
*Information in this document is subject to change
v.06.26.13
Clinton Electronics
6. SCREEN ADJUSTMENTS
While it is possible to power the monitor using the battery charger
and/or charge the battery with the DC12V power supply, doing so could
damage the product and will void the warranty.
POWER ‘ON’
POSITION
TO BATTERY
CHARGER
BATTERY
CABLE
CLR
CONTRAST
COLOR
BRIGHTNESS
