1
Top Menu
In live screen, move the mouse cursor over the top portion of the screen, or press the ▲ button on
the remote control to show the menu. Click on an icon to enter the menu. Login may be necessary.
Search Backup Status Setup Log-Out
Login Box
Before you can access any controls, you must first login with your user ID and password.
The default ID is “root” and the default password is “1111”. Click the check-mark with your mouse
cursor or press the 8 enter button on the remote to proceed.
Default Password: 1111
Remote Control / Mouse:
You can either use the supplied remote control or the two-button mouse with scroll wheel to
access and navigate OSD menus and controls. Use the supplied mouse for proper functionality.
Some selections use the left mouse button to increase, and the right mouse button to decrease.
MENUS & LOGIN
The ✔ icon Accepts a setting.
The ✖ icon Cancels out of the selection.
Bottom Menu
In the live screen, press the down button on the remote control, or move the mouse cursor over the bottom
area of the screen. The bottom menu will automatically appear.
Full
Screen
Quad
Screen
9-up 8-Mini
2-Large
12-Perimeter
Large Center
16-up 4-Mini
3-Large
