ARRANTY

ISCLAIMER

No warranties of any nature (expressed, implied, fitness of usage or merchantability) are given on these products. Seller undertakes no responsibility for any product sold.

Additional disclaimers are within and are binding upon this contract. Due to the intended usage of products offered, all products are sold on an “as-is” basis, and no

warranties of any kind, whether written or oral are made by BRODIX, Inc., its agents or employees. All implied warranties, including the implied warranties of merchantibil-

ity and fitness are expressly excluded, and the buyer bears the entire risk as to quality performance and use of these products. BRODIX, Inc. will assume no responsibil-

ity of personal injury, labor or other injury arising out of the usage of high performance racing parts or products. Any defective part will be handled between the original

manufacturer and the buyer. BRODIX, Inc. reserves the right to change specifications, prices and discontinue parts without notice. Installation of BRODIX heads may

adversely affect the vehicle manufacturer’s warranties, and may violate State and Federal laws when vehicles so equipped are operated other than strictly off-highway.

BRODIX reserves the right to discontinue any product at its sole discretion and without any liability with respect to similar products already in the field. Some parts are not

legal for sale or use on pollution controlled motor vehicles.

BLOCK PART NUMBERS

8B 5000

• 4.585 BORE, 1.0 RAISED CAM LOCATION,

11.200 DECK HEIGHT.

8B 5025

• 4.585 BORE, 1.0 RAISED CAM LOCATION,

11.625 DECK HEIGHT.

MUST SPECIFY DECK HEIGHT, CAM BEARING STYLE, LIFTER

SIZE, LENGTH OF STROKE, AND CAM LOCATION.

MAIN CAPS

MAIN STUDS AND NUTS

8B MC 454 ST-S-C-GO

8B MC 454 ST-S-C-PF

8B MC 454 ST-S-F-GO

8B MC 454 ST-S-F-PF

8B MC 454 ST-S-R-GO

8B MC 454 ST-S-R-PF

8B MS4050 1/2

8B MS4250 1/2

8B MS4650 1/2

SLEEVES

8B SL 45-330: 4.585 i.d., 4.815 o.d., 8.000 o.a.l.

8B SL 45-335: 4.585 i.d., 4.815 o.d., 7.250 o.a.l.

8B SL 45-340: 4.655 i.d., 4.875 o.d., 7.250 o.a.l.

8B SL 45-345: 4.655 i.d., 4.875 o.d., 8.000 o.a.l.

OTHER SIZES AVAILABLE,

CALL FOR DIMENSIONS AND PART NUMBERS

8B CAM BEARING ROLLER

CAM 50 mm

8B CAM BEARINGS 60 mm

BABBIT

8B CAM BEARINGS 55 mm

(ROLLER)

8B CAM BEARINGS FORD

ROLLER

55 mm BABBIT -

(SPECIAL ORDER)

8B CAM BEARING 60 mm

BABBIT

8B ORING BLOCK PLUG

8B PLUG 814-6C

8B PLUG 814-7C

8B ORING/RCAM PLUG BB

8B ORING/RCAM PLUG 55

8B RCAM PLUG 55

8B RCAM PLUG BB

8B RCAM BB RING

8B SPIRAL LOCK BB

8B SPIRAL LOCK 55

8B RCAM PLUG FORD

PLUGS AND O-RINGS

SK HS PB 5000 FOR

BRODIX HEADS

CALL BRODIX FOR PART

NUMBERS

HEAD STUDS

DOWELS

CAM BEARINGS

CAM PLUGS

OIL RESTRICTORS

8B BB OIL RESTRICTORS

(CUSTOM FOR BRODIX

BLOCK)

Not legal for sale or use on pollution controlled motor vehicles.

WHILE OUR PRODUCTS ARE USED ON MANY SUPER-CHARGED

APPLICATIONS SUCCESSFULLY, PLEASE BE AWARE

THAT THERE IS A GREATER POTENTIAL FOR ENGINE DAMAGE

DUE TO THE POSSIBILITY OF TUNING ERRORS.

PRICES ARE SUBJECT TO CHANGE WITHOUT NOTICE.

ALWAYS CONFIRM PRICE WHEN PLACING YOUR ORDER.

WE WILL MAKE EVERY EFFORT TO KEEP YOU INFORMED OF INCREASES.

CAM LOCATION AND SPECS

• 1.0 RAISED CAM

• AVAILABLE wITH ROLLER CAM BEARINGS:

50 mm

• BIG BLOCK FORD ROLLER BEARINGS:

55 mm ROLLER

• AVAILABLE wITH BABBIT BEARINGS:

55 mm BABBIT

60 mm BABBIT

• BIG BLOCK FORD BABBIT

ACCESSORIES

• STARTER BOSS ON RIGHT SIDE

• OIL FILTER LOCATION ON BLOCK

• SPECIAL HEAD STUDS AVAILABLE FROM BRODIX

• PLUG KITS INCLUDED FOR BLOCKS

• INTERNAL HEAD STUD LUG INCLUDED

HEIGHTS OF BLOCKS

• 11.200 (8B 5000)

• 11.625 (8B 5025)

• SPECIAL DECK HEIGHTS AVAILABLE

STROKE CLEARANCE

• 5.375 STANDARD

• 5.750 (wITH ADDITIONAL MACHINING)

• 4.585 i.d., 4.815 o.d., 7.250 o.a.l. (11.200 DECK)

• 4.585 i.d., 4.815 o.d., 8.000 o.a.l. (11.625 DECK)

• 4.655 i.d., 4.875 o.d., 7.250 o.a.l. (11.200 DECK)

• 4.655 i.d., 4.875 o.d., 8.000 o.a.l. (11.625 DECK)

SLEEVES

TORQUE SPECS

• OUTSIDE MAIN 85 ft-lb

• INSIDE MAIN 95 ft-lb

• VALLEY LUG BOLTS 50 ft-lb

• TORQUE wITH 30w MOTOR OIL

www.brodix.com • 301 MAPLE AVENUE • P.O. BOX 1347 • MENA, AR 71953

ORDER, TECH, AND INFORMATION: (479) 394-1075 • FAX: (479) 394-1996

MAIN CAPS

• BILLET STEEL MAIN CAPS

• 12 PT MAIN STUD NUTS

• ALIGN HONE AVAILABLE
