Ashland I-180 Narrow Rear - Manual (Page 3)

HOW TO ORDER PARTS:
IMPORTANT
Parts must be ordered through your local authorized ASHLAND dealer.
Be sure to state MODEL and SERIAL NUMBER of your machine, PART NUMBER, DESCRIPTION
and QUANTITY needed.
Unless this is done, we cannot provide prompt service or assure shipment of the correct parts.
3
I-180TS Narrow Rear
Ashland Industries weldable replacement parts are availabe to rebuild, modify or
update your scraper to current factory specifications.
Page 4. Operators and Maintenance Instructions
Page 5. Safety Guidelines
Page 6. Illustration - Assembly
Page 7. Complete Yoke Type Hitch
Page 8. Swivel Hitch Assembly
Page 9. Front Section Frame
Page 10. Lift Cylinder 5-1/2 x 20
Page 11. Lift Cylinder 5 x 20
Page 12. Apron Assembly
Page 13. Apron Cylinder old style
Page 14. Apron Cylinder new style
Page 15-16 Bowl and Frame Assembly
Page 17.
Push Off Gate Assembly
Page 18. Push Off Cylinder
Page 19. Wheel Assembly
Page 20-27 Hydraulic Plumbing
Page 28-29 Identification, Illustration, Parts List and Adjustment - Hydraulic Valve
Page 30.
Hydraulic Schmetic
Page 31-32 Grease Locations
Page 33-36 Service Manual Appendix
Page 37.
Warranty Statement
INDEX
